| Compressor Type |
Max.Working Pressure | Capacity | Motor Power | Noise | Dew Point | Tank Volume | Fiteration | Dimension(LxWxH) | Air Outlet | Weight | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| kgf/㎠G | psig | LPM | CFM | kw | HP | dB(A) | ℃ | ℓ | ㎛ | mm | A(B) | kg | |
| AL3A | 8.0 9.9 |
115 140 |
271 219 |
9.6 7.7 |
2.2 | 3 | 49 | 10 | 38 | 5 | 700x740x1450 | 15(1/2) | 210 |
| AL5A | 8.0 9.9 |
115 140 |
420 352 |
14.8 12.4 |
3.7 | 5 | 50 | 10 | 38 | 5 | 700x740x1450 | 15(1/2) | 220 |
| AL7A | 8.0 9.9 |
115 140 |
691 571 |
24.4 20.2 |
2.2x1 3.7x1 |
3x1 5x1 |
52 | 10 | 74 | 5 | 700x1530x1390 | 25(1) | 435 |
| AL10A | 8.0 9.9 |
115 140 |
840 704 |
29.6 24.9 |
3.7x2 | 5x2 | 53 | 10 | 74 | 5 | 700x1530x1390 | 25(1) | 445 |
- Specifications are subject to change without prior notice due to remodeling of products, etc.
- If moving caster adopted, height increases 40㎜.
