| Compressor Type |
Max.Working Pressure | Capacity | Motor Power | Noise | Dimension(LxWxH) | Weight | Air Outlet | |
|---|---|---|---|---|---|---|---|---|
| bar | psig | ㎥/min | kw | dB(A) | mm | kg | A(B) | |
| AS7P | 7.0 9.0 |
100 128 |
0.8 0.6 |
5.5 | 56 | 1030x640x1275 | 300 | 20(3/4) |
| AS10P | 7.0 9.0 |
100 128 |
1.2 1.0 |
7.5 | 58 | 1030x640x1275 | 310 | 20(3/4) |
| AS15P | 7.0 9.0 |
100 128 |
1.9 1.6 |
11 | 62 | 1100x700x1275 | 380 | 20(3/4) |
| AS20P | 7.0 9.0 |
100 128 |
2.5 2.2 |
15 | 68 | 1100x700x1275 | 380 | 25(1) |
- Specifications are subject to change without prior notice due to remodeling of products, etc.
