| Compressor Type |
Max.Working Pressure | Capacity | Motor Power | Noise | Dimension(LxWxH) | Weight | Air Outlet | |||
|---|---|---|---|---|---|---|---|---|---|---|
| kgf/㎠G | psig | ㎥/min | cfm | kw | HP | dB(A) | mm | kg | A(B) | |
| AS301K | 7.0 8.5 9.5 |
100 120 135 |
42.6 37 33.2 |
1504 1307 1172 |
110x2 | 300 | 82 | 3890x1850x2250 | 5872 | 100(4) |
| AS351K | 7.0 8.5 9.5 |
100 120 135 |
49.4 43.3 41.4 |
1745 1529 1462 |
132x2 | 364 | 84 | 3500x1940x2300 | 5452 | 100(4) |
| AS402K | 7.0 8.5 9.5 |
100 120 135 |
56.2 51.4 51.2 |
1985 1752 1730 |
160x2 | 428 | 87 | 3890x1850x2250 | 6372 | 100(4) |
| AS501K | 7.0 8.5 9.5 |
100 120 135 |
67.0 61.7 58.6 |
2366 2083 1942 |
200x2 | 536 | 90 | 4440x2050x2250 | 7350 | 125(5) |
- Specifications are subject to change without prior notice due to remodeling of products, etc.
