| Model | YUSOO-8 | YUSOO-15 | YUSOO-30 |
YUSOO-42 | YUSOO-100 |
|---|---|---|---|---|---|
| Container+Filling volume | 169.2L | 180.7L | 207.4L | 227.4L | 730L |
| Filling volume | 1x15.2L | 1x26.7L | 2x26.7L | 2x36.9L | 2x65L |
| Condensate inlet(hose) | 3/4＂(di=32mm) | 1＂ | 1＂ | ||
| Water outlet(hose) | 3/4＂(di=32mm) | 1＂(di=32mm) | 1＂(di=32mm) | ||
| Oil outflow | (di=32mm hose) | ||||
| Oil collector | 15 liter | 25 liter | |||
| Min/max. temperature | (+5 ~ +60℃) | ||||
| Max. operating pressure | 16bar | ||||
| Dimension | 670x550x950 | 670x700x950 | 670x700x950 | 670x700x950 | 1100x1200x1600 |
| Weight(kg) | 25 | 29 | 39 | 45 | 105 |
| Screw Compressor | Turbine Oil | 8 | 15 | 30 | 42 | 100 |
|---|---|---|---|---|---|---|
| VCL - Oil | 6.5 | 12.5 | 25 | 35.5 | 75 | |
| VDL - Oil | 8 | 15 | 30 | 42 | 100 | |
| Synthetic - Oil | 5.5 ~ 6.5 | 11 ~ 12.5 | 22.5 ~ 25 | 32 ~ 35.5 | 64 ~ 75 | |
| Piston Compressor | VDL - Oil | 6.2 | 12 | 23.5 | 29.5 | 68 |
| Synthetic -Oil | 4.5 ~ 5.5 | 9 ~ 10.5 | 16.5 ~ 19 | 22 ~ 26.5 | 51~ 60 |
