| Model | Connection (inch) |
Flow Capacity (N㎥/min) |
Inner Filter Element |
Consumption (kW) |
Dimension LxWxH (㎜) |
Weight (kg) |
|||
|---|---|---|---|---|---|---|---|---|---|
| 50Hz | 60Hz | ㎛/PPM | Size | 50Hz | 60Hz | ||||
| KYD-5HTN | PT 3/5″ | 0.6 | 0.7 | 5.1 | 15A | 0.3 | 0.35 | 427x644x775 | 56 |
| KYD-7HTN | PT 3/5″ | 0.85 | 1.0 | 5.1 | 15A | 0.31 | 0.36 | 427x644x775 | 56 |
| KYD-10HTN | PT 3/5″ | 1.2 | 1.4 | 5.1 | 15A | 0.32 | 0.37 | 427x644x775 | 56 |
| KYD-15HTN | PT 1″ | 1.6 | 1.9 | 5.1 | 20A | 0.33 | 0.38 | 453x703x1079 | 75 |
| KYD-20HTN | PT 1″ | 2.3 | 2.7 | 5.1 | 20A | 0.38 | 0.44 | 453x703x1079 | 75 |
| KYD-30HTN | PT 1″ | 3.3 | 3.9 | 5.1 | 25A | 0.91 | 1.07 | 455x875x1253 | 85 |
| KYD-50HTN | PT 8/5″ | 5.7 | 6.7 | 5 | 40A | 1.27 | 1.49 | 502x1022x1577 | 155 |
| KYD-75HTN | PT 2″ | 8.9 | 10.5 | 5 | 40A | 1.77 | 2.08 | 503x1148x1652 | 220 |
| KYD-100HTN | PT 2″ | 12.1 | 14.2 | 5 | 50A | 2.4 | 2.82 | 559x1289x1737 | 245 |
- R-134A refrigerant on models HYD-5HTN~20HTN and R-22 refrigerant on models HYD-30HTN and above.Upon request for R-404A or R-407C refrigerant.
- 1 phase on models HYD-75HTN and below and other electric power is abailable.
- Above flow rate is based on 60Hz.
- Upon request for customer-engineered products.
- The specifications can be changed without notice to improve the quality.
