| Model | Capa | Connection | Dimension(mm) | Weight | |
|---|---|---|---|---|---|
| N㎥/min | PT | W | H | Kg | |
| KYF-15A | 1.0 | PT 15A | 105 | 270 | 1.5 |
| KYF-20A | 1.9 | PT 20A | 105 | 310 | 1.5 |
| KYF-25A | 3.4 | PT 25A | 105 | 435 | 1.9 |
| KYF-40A | 10.0 | PT 40A | 144 | 700 | 12.0 |
| KYF-50A | 14.0 | PT 50A | 185 | 930 | 21.0 |
| KYF-65A | 28.0 | FLG 65A | 550 | 1105(1993) | 88.0 |
| KYF-80A | 42.0 | FLG 80A | 550 | 1105(1993) | 103.0 |
| KYF-100A | 70.0 | FLG 100A | 600 | 1125(2005) | 120.0 |
| KYF-125A | 84.0 | FLG 125A | 700 | (2035) | 170.0 |
| KYF-150A | 112.0 | FLG 150A | 700 | (2035) | 180.0 |
| KYF-200A | 196.0 | FLG 200A | 1000 | (2367) | 300.0 |
- KYF15A ~ 50A has AL die-casting structure, KYF 65A ~ 100A : HOUSING-stainless, HEAD-AL die-casting.
- Stand : 125A(optional), 150A ~ 300A(standard)
