| Model | Capacity | Port Diameter | Dimension (mm) | Weight | |
|---|---|---|---|---|---|
| N㎥/min | FLG | W | H | Kg | |
| GF/PF/HF/DF/CF 1080K | 60.00 | 4＂ | 510 | 1076 | 155.0 |
| GF/PF/HF/DF/CF 1500K | 83.33 | 6＂ | 580 | 1248 | 195.0 |
| GF/PF/HF/DF/CF 2250K | 125.00 | 8＂ | 800 | 1410 | 203.0 |
| GF/PF/HF/DF/CF 3000K | 166.66 | 8＂ | 800 | 1410 | 206.0 |
| GF/PF/HF/DF/CF 4500K | 250.00 | 10＂ | 1000 | 1530 | 302.0 |
| GF/PF/HF/DF/CF 6000K | 333.33 | 12＂ | 1091 | 1700 | 405.0 |
- Capacity is based on Inlet pressure of 7barG. Maximum and minimum pressures are 9.7barG / 2barG, and maximum and minimum temperatures are 65°C / 2°C.
- Manometer applied to GF/PF/HF/DF (excluding CF) models
- Standard is to attach float drain for GF/PF/HF models and manual drain for DF/CF models.
- Drain Port Size : One Touch 6φ
| Type | Application |
|---|---|
| GF | 10㎛ 99.9% |
| PF | 1㎛ 99.999% |
| HF | 0.01㎛ 99.999% |
| DF | 1㎛ 99.999% |
| CF | 0.003ppm, Removal of oil gas and smell |
| Inlet Pressure(bar) | 2.0 | 2.9 | 3.9 | 4.9 | 5.9 | 6.9 | 7.8 | 8.8 | 9.8 | 10.8 | 11.8 | 12.7 | 13.7 | 14.7 | 15.7 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Correction Factor | 0.40 | 0.50 | 0.62 | 0.75 | 0.87 | 1.00 | 1.11 | 1.22 | 1.34 | 1.47 | 1.58 | 1.71 | 1.83 | 1.95 | 2.07 |
