Model	Capacity	Power Consumption	Range of Ambient Temperature	Range of Inlet Temperature	Power	Refrigerant	Diameter of Port	Dimension	Weight
	N㎥/min	kW	℃	℃	V/Ph/Hz		FLG	LxWxH(mm)	kg
JHT25	0.85	0.50	2~40	4~80	220V/ 1ph/ 50/60Hz	R-134a	3/4＂	731x363x681	42
JHT35	1.30	0.50					3/4＂	731x363x681	43
JHT50	1.92	0.71					3/4＂	741x443x901	63
JHT75	2.73	0.71					1＂	741x443x951	69
JHT100	3.50	0.78					1＂	741x443x951	69
JHT200	6.83	1.90		4~65		R-22	1 1/2＂	891x593x1291	123

• Capacity is based on Inlet temperature of 60°C, Ambient temperature of 35°C, Inlet pressure of 7barG and pressure dew point of 10°C
• Maximum pressure for JHT25~35:9.7barG, for JHT50~200:16barG
• Drain port size of all models: 1/4”

Inlet Pressure	13	16
Correction Factor	1.18	1.23

Inlet Temperature	40	45	50	55	60	65	70	75	80
Correction Factor	1.17	1.14	1.1	1.05	1.00	0.94	0.89	0.84	0.80

Ambient Temperature	25	30	32	35	38	40
Correction Factor	1.24	1.10	1.04	1	0.93	0.82
